Drawell Vertical Automatic Medical Autoclave Sterilizer Price

FOB Reference Price:Get Latest Price
$140.00 - $4,900.00 / Set | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 100 Sets)
Customized packaging (Min. Order: 100 Sets)

More

Graphic customization (Min. Order: 100 Sets) Less
Samples:
$140.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
Drawell
Model Number:
DW-C Series
Type:
Pressure Steam Sterilization Equipments
Warranty:
1 year
After-sale Service:
Online Technical Support
Instrument classification:
Class I
Volume:
35L/50L/75L/100L/120L/150L
Chamber Size:
300*485/320*545/388*480/388*630/460*590/460*700mm
Working Temperature:
115-129℃
Working Pressure:
0.145-0.165Mpa
Time scope:
0-80min
Packing Size:
67*68*128cm
G.W:
49/60/80/85/97/110kgs
Power:
AC220V/50Hz/2.5KW
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard Export Package With English Language
Port
Shanghai,Guangzhou,Qingdao,Dalian,Lianyungang,Ningbo,Shantou
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated

DW-B Vertical Autoclave


Features:
High quality SUS304 stainless steel material
Dual scale indicate pressure gauge
Light indicate working status
Temperature, time of sterilization can be set.
Water lack auto-protection
Over pressure auto-discharging
Over current auto-protection
Over temperature auto-protection
Drying function can be add(best large than 75L)



Model

DW-B35L

DW-B50L

DW-B75L

Volume

35L

50L

75L

Chamber size

 Φ300*485mm

Φ320*545mm

 Φ388*480mm

Working temperature

115-129℃

115-129℃

115-129℃

Working pressure

0.145-0.165Mpa

0.145-0.165Mpa

0.145-0.165Mpa

Time scope

0-80min

0-80min

0-80min

Packing size

53*52*92cm

56*56*105cm

62*60*109cm

G.W/N.W

49kg/34kg

60kg/40kg

80kg/57kg

Power

AC220V/50Hz/2.5KW

AC220V/50Hz/2.5KW

AC220V/50Hz/3.5KW

Model

DW-B100L

DW-B120L

DW-B150L

Volume

100L

120L

150L

Chamber size

 Φ388*630mm

Φ460*590mm

 Φ460*700mm

Working temperature

115-129℃

115-129℃

115-129℃

Working pressure

0.145-0.165Mpa

0.145-0.165Mpa

0.145-0.165Mpa

Time scope

0-80min

0-80min

0-80min

Packing size

63*61*118cm

66*67*121cm

67*68*128cm

G.W/N.W

85kg/66kg

97kg/75kg

110kg/80kg

Power

AC220V/50Hz/4.0KW

AC220V/50Hz/4.0KW

AC220V/50Hz/4.0KW
